In the two models are fitted with frames and frameless around the glass.

The selection of these two  models is elegantly and suit to the Surroundings.

Design and Insulation of  frames is in such a way that prevent the entry of dust, foreign matter and noise in the upper limit.

Engine (75 V) DC 24 V

• Smart andcombined helical gear Engine to increase power and reduce noise
• Ergonomic design to prevent Engine overheating
• Using Of Cogwheel for stimulating strap and its retentive
• Engine without coal
• Smart electric locking system of  inside the engine
• Without the need for long-term service

micro-computer

• Smart micro-computer checks all  parameters at any moment and all parameters are adjustable correctly.
• Quick and easy connect of accessories with using of socket
• Ability to set the direction of motion of opening for single leaf doors
• Ability to set for installation of external electro-mechanical locks

Intelligent systems of engine electric lock

Electric lock inside the engine acts intelligently after activation via remote control and when pressure is applied to open the doors, the system immediatly resists with the power multiplier of exerted pressure and prevents to open the door. If trying to open doors countinues, the engine completely locked and remains in this state for 20 seconds. And the system returns to normal operation if you don’t try again to open the door.

• Electro Sensitive Safety Devices between the doors
• Permanent open mode
• Open and shut case
• Setting the half-open state (Winter)
• To Enable and disable the electric lock
• microwave motion sensor with high sensitivity
• Precise adjustment functional range
• Lack of sensitivity to the sun
• Pulleys made of special Teflon highly resistant to abrasion and quiet with long life

Double Interior	Single Interior	model
On the wall - on the chassis	On the wall - on the chassis	Ability to install
kg 150 * 2	kg 160 * 1	Weight tolerable
600 - 1250 mm	mm 1300 - 700	Opening each door Interior width
24 v DC 75 w) - Without Coal)		Engine
cm per second 45 ~ 15	15 ~ 50 cm per second	Speed of opening the door
cm per second 43 ~ 10	Adjustable  45~10	Speed of closing the door
8-10   sec		Time to stay unlock doors
Half open mode for winter setting / adjustable from the remote control		Half-open state
Nioton 42	Nioton 39	Unlock manually in silent mode
Fast  opening performance when  sudden strike		The bumpers Performance
50/60MHz  volt 250 ~ 200 AC		Voltage and current consumption
no-load mode 095/0 A		The current
under load 60/1 A	under load 35/1 A
20- - +50 °C		Working ambient temperature
Electronic locks inside the engine - Remote control		System equipment
UPS - card reader - fingerprint - barcode reader - key status determination		Options can be added
